General
|
Capacity (VA) |
3500 |
Capacity (Watts) |
2450 |
Input
|
Generator Compatibility |
Yes |
Nominal Input Voltage (Vac) |
220, 230, 240 |
Input Voltage Range (Vac) |
140 ~ 300 Vac |
Input Frequency (Hz) |
50 ± 5, 60 ± 5 |
Input Frequency Detection |
Auto-sensing |
Input Connector Type |
Hardwire Terminal Block |
Output
|
Output Waveform |
Pure Sine Wave |
Output Voltage(s) (Vac) |
220 ± 5%, 230 ± 5%, 240 ± 5% |
Output Frequency (Hz) |
50 ± 1%, 60 ± 1% |
Automatic Voltage Regulation (AVR) |
Single Boost, Single Buck |
Overload Protection (On Utility) |
Circuit Breaker |
Overload Protection (On Battery) |
Internal Current Limiting |
Manual Switch |
Normal, Bypass with AVR, Bypass, Off |
Outlet(s) - Total |
3 |
Outlet Type |
Hardwire Terminal Block x 1, Schuko x 2 |
Typical Transfer Time (ms) |
10 |
Surge Protection & Filtering
|
Lightning / Surge Protection |
Yes |
Management & Communications
|
LCD Panel |
Yes |
LED Indicators |
Power On, Wiring Fault |
Audible Alarms |
Battery Mode, Low Battery, Overload, Overcharge, Overheat |
Power Management Software |
PowerPanel® Business (Recommended) |
SNMP / HTTP Remote Monitoring |
Yes - with optional RMCARD205 |
Physical
|
Wheels |
Yes |
Physical Size
|
Dimensions (WxHxD) (mm.) |
260 x 440 x 330 |
Weight (kg.) |
36.53 |
Environmental
|
Operating Temperature (°C) |
0 ~ 40 |
Operating Relative Humidity (Non-condensing) (%) |
0 ~ 95 |
Certifications
|
Certifications* |
CE, EAC, SONCAP |
RoHS |
Yes |
External Battery (Optional)
|
Battery Type |
Sealed Lead-acid |
Battery Voltage (Vdc) |
24 |
