Input
|
Nominal Input Voltage (Vac) |
100 ~ 240 |
Input Frequency (Hz) |
50 / 60 |
Maximum Input Current (A) |
16 |
Input Connector Type |
IEC C20 x 1 |
Power Cord Length (m.) |
3.05 |
Output
|
Outlets - # of Bank(s) (Bank) |
1 |
Outlet(s) - Total |
8 |
Outlet(s) - Front |
8 |
Outlet Type |
IEC C13 x 8 |
Management & Communications
|
LCD Information Display |
Input Voltage (Volts), Input Frequency (Hz), Current Level (Amps), Power Consumption (Kilowatts), Network Information, Serial Number, Environment Status, Hardware Version,
Firmware Version |
LED Indicators |
PDU Status, Tx/Rx, Link, Outlet |
A-type USB Port |
Yes |
Connectivity Port |
RJ45, RJ45 (for Serial), RJ45 (for ENVIROSENSOR/ Daisy Chain (In)), RJ45 (for Daisy Chain (Out)) |
Environmental Sensor Supported |
Yes |
Power Management Software |
PowerPanel Business (Recommended for small-medium scale management), PowerPanel Enterprise (Recommended for large scale management) |
Supported Protocols |
IPv4/v6, SNMPv1/v3, HTTP/HTTPs, TCP/IP, UDP, DHCP, NTP, DNS, SMTP, SSH, SSL, TLS, Telnet, FTP, and Syslog |
Authentication |
RADIUS, LDAP, LDAPS, Windows AD |
Physical
|
Installed Rack Height (U) |
1 |
Cord Retention Tray |
Yes |
IEC Receptacle Locking |
Yes |
Physical Size
|
Dimensions (WxHxD) (mm.) |
433 x 44 x 112 |
Weight (kg.) |
2.1 |
Environmental
|
Operating Temperature (°C) |
0 ~ 60 |
Operating Relative Humidity (Non-condensing) (%) |
0 ~ 95 |
Certifications
|
Certifications* |
CE, FCC Class A, UL60950, UL62368, EN 55032 Class A |
RoHS |
Yes |
