SSP-600JT
- Параметри: Power supply 600W, APFC, 12cm fan, ATX 12V v.2.3, 80+ gold, DC to DC converter design, MTBF full load 25? amb. : >100K hours; SSP-600JT
- Други: Fully Fixed
- Гаранция: 36 m
- Наличност: на склад
- Цена с включен ДДС: 126.32 BGN
Технически данни
| Overview | ||
|---|---|---|
| ATX Compatibility | Intel ATX 12 V v2.3 compliant | |
| Dimensions | 140 × 150 × 86 mm | |
| Circuit design | DC to DC converter design | |
| Fan | 120 mm double ball bearing fan | |
| Fan Control | S2FC | |
| Protections | SCP, OVP, OPP | |
| Connections | PCIe | |
| Quality Control | Burn-in, high temperature cycled on/off | |
| Safety and Environmental Compliance | CB, cTUVus, TUV, CCC, BSMI, RCM(SAA) | |
| Technical Specifications | ||
|---|---|---|
| Input Frequency | 50 / 60 Hz | |
| Efficiency | 80PLUS® Gold | |
| Line Regulation | ‡ 1% (typical) | |
| Load Regulation | ‡ 5 % (typical) | |
| Cross Regulation | ‡ 5 % (typical) | |
| MTBF, full load @ 25 °C ambient (excl. DC fan) | > 100,000 hours | |
| Active Power Factor Correction | 99 % (typical) | |
| DC Output | |||||||
|---|---|---|---|---|---|---|---|
| +3.3V | +5V | +12 V Combined | -12 V | +5 Vsb | Total Continuous Power | Input Type | |
| 20A | 25A | 50A | 0.5A | 3A | 600 W | 100-240 VAC | |
| 125 W(max.) | 600 W(max.) | 6 W | 15 W | ||||
