HD6500

HD6500 image click to zoom

  • Параметри300-bay High density storage server (60 bays on base, up to 300 bays with 4x RX6022sas)
  • Други:  2x Intel Xeon 4210R, 64GB RAM, 2x 10GbE, 2x 1GbE, 4U rackmount
  • Гаранция60 m
  • Наличностс поръчка
  • Цена с включен ДДС: 34290.00 BGN

Технически данни

CPU
CPU Model Intel Xeon Silver 4210R
CPU Quantity 2
CPU Architecture 64-bit
CPU Frequency 10-core 2.4 (base) / 3.2 (turbo) GHz
Hardware Encryption Engine (AES-NI)
Memory
System Memory 64 GB DDR4 ECC RDIMM
Memory Module Pre-installed 64 GB (32 GB x 2)
Total Memory Slots 16
Maximum Memory Capacity 512 GB (32 GB x 16)
Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.
Storage
Drive Bays 60
Maximum Drive Bays with Expansion Unit 300 (RX6022sas x 4)
SAS multipathing
Compatible Drive Type* (See all supported drives)
  • 3.5" SAS HDD
  • 2.5" SATA SSD (system drives)
Hot Swappable Drive
Notes
  • Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability.
  • Two Synology 480GB SATA SSDs are included in the accessory pack.
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port 2 (with Link Aggregation / Failover support)
Management LAN Port 1
Max. number of LAN ports 15
USB 3.2 Gen 1 Port* 2
Expansion Port 2
Notes
  • The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
  • Besides the 5 built-in LAN ports, up to 10 additional LAN ports can be made available by installing compatible network interface cards (sold separately).
PCIe
PCIe Expansion
  • 2 x Gen3 x16 slot (x16 link)
  • 2 x Gen3 x8 slots (x8 link)
File System
Internal Drives
  • Btrfs
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT
Notes exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center.
Appearance
Form Factor (RU) 4U
Size (Height x Width x Depth) 176 mm x 482 mm x 1020 mm
Weight 37.9 kg
Rack Installation Support* 4-post 19" rack (Synology Rail Kit - RKS-03)
Others
System Fan 80 mm x 80 mm x 4 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Easy Replacement System Fan
Power Recovery
Noise Level* 60.8 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 1600 W
Redundant Power Supply
AC Input Power Voltage 200V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 1025.2 W (Access)
418 W (HDD Hibernation)
British Thermal Unit 3495.93 BTU/hr (Access)
1425.38 BTU/hr (HDD Hibernation)
Notes
  • Noise Level Testing Environment: Fully loaded with Synology HAS5300-8T hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
  • Power consumption is measured when it is fully loaded with Synology 8TB HAS5300-8T hard drive(s).
Temperature
Operating Temperature 0°C to 35°C (32°F to 95°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
  • UL
Warranty
5 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Synology 480GB SATA SSD X 2
  • Rail Kit Sliding: RKS-03 X 1
  • Accessory Pack X 1
  • AC Power Cord X 2
  • Quick Installation Guide X 1
Optional Accessories
DSM Specifications
Maximum Single Volume Size*
  • 1 PB (for RAID 6 groups only)
  • 200 TB
Maximum Internal Volume Number 256
RAID Group
Supported RAID Type
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
Volume Expansion with Larger HDDs
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
Volume Expansion by Adding a HDD
  • JBOD
  • RAID 5
  • RAID 6
Global Hot Spare Supported RAID Type
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
Notes On Peta Volume enabled volumes, Snapshot Replication, shared folder encryption, and compression will not be available. Please refer to this article for more information on limitations.
File Protocol SMB/AFP/NFS/FTP/WebDAV
Maximum Concurrent SMB/AFP/FTP Connections 6,000
Maximum Concurrent SMB/AFP/FTP Connections (with RAM expansion) 6,000
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
Notes
  • Regarding data concerning tests with RAM expansion, all memory slots are installed with the maximum capacity of supported RAM.
  • The testing standard was based on the maximum number of concurrent connections supported by this model. During the testing, 25% of the connections were used to transfer files concurrently. The transfer process guaranteed that the connections were not interrupted; the minimum transfer speed was not guaranteed.
Maximum Local User Accounts 16,000
Maximum Local Groups 512
Maximum Shared Folder 512
Maximum Shared Folder Sync Tasks 32
Maximum Hybrid Share Folders 30
Notes For more details about the maximum number of Hybrid Share folders, check this article.
Synology High Availability
Syslog Events per Second 6,000
Virtualization
Citrix Ready
OpenStack
Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers
  • Google Chrome
  • Firefox
  • Microsoft Edge
  • Safari
Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Notes For an updated list of supported browser versions, check the DSM Technical Specifications.
Antivirus by McAfee (Trial)
Maximum Number of Concurrent Users 500
Notes
  • Measured with simulated users, each with an average record of 20,000 messages, emojis, or stickers. The required server response time is below ten seconds.
  • When applicable, systems are tested configured with maximum memory and set to allow the maximum number of connections.
Maximum iSCSI Target Number 256
Maximum LUN 512
LUN Clone/Snapshot, Windows ODX
Free Email Accounts 5 (Licenses required for additional accounts)
Maximum Number of Concurrent Users 800
Maximum Server Performance 2,895,678 emails per day, approx. 85 GB
Notes
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers.
  • Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).
Maximum Snapshots per Shared Folder 1,024
Maximum of System Snapshots 65,536
Maximum IP cam (Licenses required) 150 (including 2 Free License) (see all supported IP cameras)
Total FPS (H.264) 4500 FPS @ 720p (1280x720)
2800 FPS @ 1080p (1920x1080)
1280 FPS @ 3M (2048x1536)
850 FPS @ 5M (2591x1944)
600 FPS @ 4K (3840x2160)
Total FPS (H.265) 4500 FPS @ 720p (1280x720)
4500 FPS @ 1080p (1920x1080)
2700 FPS @ 3M (2048x1536)
1500 FPS @ 5M (2591x1944)
1120 FPS @ 4K (3840x2160)
Notes
  • Maximum IP cameras and FPS figures are tested with the device fully populated with drives and under a continuous recording setup.
  • Actual system capabilities may differ depending on system configuration, drive performance, number of features enabled, and if additional workloads are present.
  • Tested using RAID 5 configuration with the maximum number of supported SAS drives.
Recommended Number of Concurrent Sync Clients 2,000 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Recommended Number of Hosted Files 100,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Notes
  • Exceeding the recommended numbers above will not block application operations, but may result in longer response time.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.
Maximum Users 3,400
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Recommended Virtual Machine Instances 40 (Learn more)
Recommended Virtual DSM Number (Licenses required) 40 (including 1 Free License)
Notes The specifications vary depending on system configuration and memory size.
Maximum Connections 60
